16-Port full gigabit optical+4G combo Managed Industrial Switch, Rak-moutable #EL1612GSMI

Model No.

EL1612GSMI

1000Base-FX Port

16 Port SFP

1000Base-TX/FX Port

4G combo (either 4G RJ45 or 4G SFP)

Performance Specification

Bandwidth: 256Gbps
Packet Buffer Memory: 16Mbit
Packet Forwarding Rate: 131Mpps

MAC Address Table: 16K

Installation

Rak mounted

Maximum Frame Size

10240bytes packet size

Flow Control

Back pressure for half duplex, IEEE 802.3x pause frame for full duplex

Enclosure

IP40 Aluminum housing

LED Indicator

Power: Red

Fiber: Link (Green)

Ethernet: Yellow

Power Input

DC36-72V, AC100-240V

Power Consumption

< 30W

Surge protection

 ± 4KV

Network Protocols

IEEE802.3 10BASE-T;

IEEE802.3i 10Base-T;

IEEE802.3u;100Base-TX/FX;

IEEE802.3ab 1000Base-T;

IEEE802.3z 1000Base-X;

IEEE802.3x;

Network cables

10BASE-T: Cat3,4,5 UTP(≤100 meter)

100BASE-TX: Cat5 or later UTP(≤100meter)

1000BASE-TX: Cat6 or later UTP(≤100 meter)

Industry Standard

FCC CFR47 Part 15,EN55032 Class A

IEC61000-4-2 (ESD): ±8kV (contact), ±12kV (air)

IEC61000-4-3 (RS): 10V/m (80~1000MHz)

IEC61000-4-4 (EFT): Power Port: ±4kV; Data Port: ±2kV

IEC61000-4-5 (Surge): Power Port: ±2kV/DM, ±4kV/CM; Data Port: ±2kV

IEC61000-4-6 (CS): 3V (10kHz-150kHz); 10V (150kHz-80MHz)

IEC61000-4-16 (Common mode conduction): 30V (cont.), 300V (1s)

MTBF

300,000hours

Dimensions (W x D x H)

442×325×44mm

Weight

Product Weight: 4KG

Packing Weight: 4.5KG

Working Environment

Working temperature: -40～75℃ ;

Storage temperature: -40～75℃

Relative Humidity: 5%~95 %( no condensation)
