8 Port 10/100+2G SFP Industrial Switch
EL1082FG-SFP
Key Words
Features
- 8*10/100 Ethernet+2G SFP
- Plug and play, no configuration required
- Store-and-forward switching architecture
- Supports 240W PoE output
- Fanless design for silent operation
Specifications
Product Name | 8-Port 100Mbps RJ45+2 Port 1000Mbps SFP Industrial Switch |
Model No. | EL1082FG-SFP |
Ethernet interface | |
RJ45 Port | 8*10/100BaseT(X),Automatic detection, Full/half duplex MDI/MDI-x adaptive |
Optical port | 2*1000Base-FX port SFP uplink (Support 1*9 fixed optical SC,ST,FC interface, optional ) |
Power Parameters |
|
Power | Connection: 1 removable 5-contact terminal block(s) Input voltage: DC12 to 52V redundant power support reverse connection protection |
LED Indicator | Power: Green Link: Green |
Standards | |
Network Protocols | IEEE802.3-10BaseT、IEEE802.3u-100BaseTX/100Base-FX、IEEE802.3x-Flow Control、IEEE802.3z-1000BaseLX、IEEE802.3ab-1000BaseTX、IEEE802.1ab、IEEE802.1D-Spanning Tree Protocol、IEEE802.1w-Rapid Spanning Tree Protoco、APS |
Twisted Pair | 10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or later UTP(≤100 meter) |
One-click switcher | Switcher for HSR (RING connection) Switcher for Vlan Isolation between downlink port |
Switch Properties | |
Processing Type: | Store and Forward |
MAC Table Size | 8K |
Packet Buffer Size | 4Mbit |
Bandwidth | 26G |
Switching Delay | < 10μs |
Power Consume | ≤ 5W |
Physical Characteristics | |
Protection level | IP40 |
Enclosure | Wavy aluminum alloy |
Installation | Push-in DIN rail |
Weigh | 1.0kg |
Dimensions | 150x125x53mm（length x width x height) |
Environmental Limits | |
Working temperature | -40～75℃ （-40～167 °F） |
Storage Temperature (package included) | -40 to 85°C (-40 to 185°F) |
Ambient Relative Humidity | 5 to 95% (non-condensing) |
Standards and Certifications | |
Safety | EN 62368-1(LVD) |
EMI | FCC Part 15 Subpart B Class A，EN 55032 Class A |
EMS | IEC(EN)61000-4-2(ESD): ±8kV Contact, ±8kV Indirect,±15kV Air IEC(EN)61000-4-3(RS):10V/m(80～1000MHz) IEC(EN)61000-4-4(EFT): power line:±4kV; data line:±2kV IEC(EN)61000-4-5(Surge): power:±6kV CM/±4kV DM; data:±4kV IEC(EN)61000-4-6(RF conduction):3V(10kHz～150kHz),10V(150kHz～80MHz) IEC(EN)61000-4-16(Common mode conduction):30V cont. 300V,1s IEC(EN )61000-4-8 |
Shock | IEC 60068-2-27 |
Freefall | IEC 60068-2-32 |
Vibration | IEC 60068-2-6 |
MTBF | |
Time | 300 000hrs |
Warranty | |
Warranty Period | 5years |
